FiloSlim cable repair

The FILOSLIM Cable Sheath Repair Kit utilizes a totally enclosed mix-and-pour polyurethane resin technology, designed for use as a permanent repair of damaged cable sheaths.

The combination of the Filoform 3D Gauze and the FILOSLIM Injection Resin, enables a quick and easy method of sealing and protecting damaged areas; whilst the hydrocarbon resistant outer sealing tape offers protection in the tough conditions found in direct buried and free-standing applications.

Cables can be buried immediately after the pouring of the resin, and full cure is achieved after one hour. This makes it a quick and reliable alternative to heatshrink repair sleeves but with the added mechanical protection of a hard curing resin. This lends itself to applications where there is a probability or risk of moisture ingress or flooding.

The FILOSLIM LV cable jointing system is approved in accordance with NEN EN 50393 & IEC 60455-3-8:2013

• No heat source required
• No specialist tools
• Enclosed mixing and pouring
• Suitable for cables up to 170mm diameter as standard
• Suitable for use as a moisture seal
• Suitable for direct buried and vertical applications
• Suitable as an outer seal on EPR, XLPE, PVC and PILC LV and MV cable sheaths
• Void filling properties of the resin, negate the requirement for additional mastic tapes or gap fillers
• Seawater resistant
• Hydrocarbon resistant
• Kit contains all components required; including the resin, tape, nozzles and gloves
• Can be de-laminated (tape and blue injection valve can be removed, when cured)

Please click HERE to download a datasheet
